LINNO Recessed

27_Linno_120_Recessed

LINNO Recessed

Linno

PRODUCT SPECIFICATION

Aluminum housing
Electro static Powder coating in different colors
Available in 1140 ,860 ,580 ,360 mm Diameters
Anti UV PMMA diffuser with homogeneous light
distribution
Additional profile for semi recessed mount and
to point different angles
Polyamide terminal with through wiring
High efficiency LED SMD modules with L90F50
50000h lifelong
CRI >80 and macAdam step 3
Dimmable ECG with %95 efficacy and >0.97 Ø

Showing all 4 results

Cross Section View

Technical detail

LINNO PMi

Reference Power Luminous flux efficacy Diameter
NLI 40 PMi 19 w 28 w 2152 lm   3075 lm 109.8 lm/w 113 lm/w 36 cm
NLI 60 PMi 28 w 44 w 3780 lm 5790 lm 135 lm/w 131 lm/w 58 cm
NLI 90 PMi 54 w 90 w 7590 lm 12000 lm 140 lm/w 133 lm/w 86 cm
NLI 120 PMi 78 w 159 w 10650 lm 21000 lm 136 lm/w 132 lm/w 114 cm

Visual Specification
